How Do I Disassemble My Asus GL-753V?

Select Language:

Disassembling your Asus GL-753V can seem daunting, but with the right guidance and a systematic approach, it can be done efficiently. Whether you’re looking to upgrade components, clean the internals, or perform repairs, this guide will provide step-by-step instructions to help you through the process safely.

Tools Needed

Before starting the disassembly, gather the necessary tools:

Phillips screwdriver (medium size)

Plastic pry tools or spudgers

Tweezers (optional)

Anti-static wrist strap (recommended)

Safety Precautions

It’s vital to take safety precautions to avoid damaging your laptop or injuring yourself:

Power down the laptop and unplug it from any electrical source.

Remove the battery if applicable (some models have a removable battery).

Work in a static-free environment to prevent electrostatic discharge (ESD) damage.

Step-by-Step Disassembly Process

Step 1: Remove the Bottom Panel

Flip the laptop over so the bottom is facing up.

Locate and remove all visible screws. These are typically Phillips screws that hold the bottom panel in place.

Use a plastic pry tool to gently separate the bottom panel from the laptop casing. Be careful not to force anything to prevent cracking the plastic.

Step 2: Disconnect the Battery

Once the bottom panel is off, locate the battery connector.

Gently disconnect the battery cable from the motherboard. Take your time, as excessive force can damage the connector.

Step 3: Remove the Hard Drive and RAM

For the Hard Drive:
- Locate the hard drive bay.
- Unscrew any screws holding the hard drive in place.
- Carefully slide the hard drive out of its bay.

For the RAM:
- Identify the RAM slots next to the CPU.
- Release the clips on either side of the RAM module and carefully pull the memory stick straight out.

Step 4: Take Out the Optical Drive (if applicable)

Find the screws securing the optical drive.

Remove these screws and gently slide the optical drive out of the laptop casing.

Step 5: Remove the Cooling Assembly

Locate the screws securing the cooling assembly (fans and heat sinks).

Unscrew and carefully remove the cooling assembly.

Disconnect any fan cables from the motherboard for full removal.

Step 6: Access the Motherboard

With the cooling assembly removed, identify the remaining screws that secure the motherboard.

Unscrew these screws and carefully lift the motherboard from the laptop housing.

Ensure that any cables or connectors are fully detached before lifting.

Reassembly Tips

After completing your tasks inside the laptop, it’s crucial to reassemble everything properly:

Replace the motherboard, ensuring all connectors and screws are secure.

Reinstall the cooling assembly and secure all screws.

Reattach the RAM and hard drive carefully, ensuring proper alignment in their slots.

Reconnect the battery and replace the bottom panel, securing it with screws.

Final Checks

Before powering your device back on, double-check the following:

All screws are tightened and secure.

Cables and connectors are correctly plugged back into their respective ports.

The battery (if removed) is reconnected.

Following these steps will allow you to disassemble and reassemble your Asus GL-753V effectively, whether for maintenance, upgrades, or repairs. Always take your time, and don’t hesitate to consult additional resources if needed.
