How to Upgrade Your HP Omen 17 to Wi-Fi 7 Tri-Band

Select Language:

If you’re looking to upgrade your PC’s Wi-Fi capabilities to the latest standard, you might be interested in making the jump to Wi-Fi 7. While it’s common for many models to not ship with Wi-Fi 7 adapters, don’t worry—upgrading is usually still an option. Here’s a step-by-step guide on how to successfully install a Wi-Fi 7 card in your computer.

First, you’ll want to identify if your PC is compatible. If your device has an Intel 12th generation core processor, like many in the HP model series, you can likely proceed with the upgrade. Although there haven’t been many documented attempts to install a Wi-Fi 7 card in these models, there’s a good chance it can work without any BIOS issues.

The recommended adapter for this upgrade is the Intel BE200 M.2 2230 Wi-Fi 7 + Bluetooth 5.4 card, specifically HP part # N39883-001. Before you begin the installation process, make sure you have the right tools on hand, including a screwdriver and possibly an anti-static wrist strap to protect your components.

Here’s how to install your new Wi-Fi card:

Gather Your Supplies: In addition to the Wi-Fi card, you’ll need a small Phillips screwdriver, the maintenance service guide, and a video tutorial for assistance if needed.
Prepare Your Workspace: Make sure to work in a clean, static-free area. Wear an anti-static wrist strap if you have one.
Power Down and Unplug Your PC: Before you start, completely shut down your computer and unplug it from the power source. If you’re using a laptop, remove the battery if possible.
Open the Case: Follow the maintenance service guide to safely open your computer’s case. This link will provide you with a detailed manual to help you navigate: Maintenance and Service Guide.
Locate the WLAN Card: Carefully identify the current Wi-Fi card. Look for a small card connected with thin antenna wires.
Detach the Antenna Wires: Be careful while removing the delicate antenna wires. It’s crucial not to damage them during this process. Take note of where the wires are connected, as they will need to be reattached to the new card later.
Remove the Old Card: Unscrew the old card gently, paying attention to how it is installed. Slide it out from its slot.
Install the New Wi-Fi 7 Card: Carefully insert the Intel BE200 card into the same slot. Secure it in place with the screws you previously removed.
Reconnect the Antenna Wires: Attach the antenna wires to the new card. Ensure they fit snugly without forcing them, as they are delicate.
Close Your Computer: Replace the cover of your PC, and if you removed a battery, reinsert it.
Power Up and Test: Plug your PC back in and power it up. Check your network settings to confirm the new adapter is recognized and functioning correctly.

For more visual guidance, check out this video that shows how to replace parts on an HP Omen laptop: Removing & Replacing Parts for OMEN by HP 17 Laptop. While it may not be specific to the 17-ck model series, it can offer valuable insights and tips.

By following these steps, you can successfully upgrade your PC’s Wi-Fi capabilities. Enjoy the enhanced performance that comes with a Wi-Fi 7 adapter!
