Are you looking for information about the Cupertino 3 and Cupertino 2 motherboards, but finding it difficult to locate user manuals or detailed specifications? You’re not alone! Many users encounter this issue as HP does not provide comprehensive documentation for its motherboards. However, in this guide, I’ll show you how to find the key specifications and compatible components of these motherboards while providing guidance on making the most out of your system.

Start by identifying your motherboard model. The Cupertino 3 motherboard (part number 682953-001) and the Cupertino 2 motherboard (part number 657002-001) are commonly used in HP desktops. You can find important information and parts through the HP PartSurfer website. Here are the links for your reference:

Once you have the right model, you can look for specifications for the Cupertino 3 motherboard, which features the Intel H61 chipset. Here’s a quick overview of the essential details:

Form Factor: 9.6 inches x 8.7 inches
Manufacturer: Foxconn
Chipset: Intel H61
Memory Slots: 2 x DDR3
Front Side Bus Speeds: 5 GT/s

Understanding Expansion Slots

This motherboard has several expansion slots that can help you upgrade your computer:

1 x PCI Express x16 (Gen 2.0)
3 x PCI Express x1 (Gen 2.0)
1 x PCI Express Mini Card x1

Supported Processors

Here are some compatible processors for the Cupertino 3 motherboard:

Intel Core i7 and i5 (Ivy Bridge and Sandy Bridge) with various TDPs (thermal design power) ranging from 35W to 95W
Intel Core i3 (both Ivy Bridge and Sandy Bridge)
Intel Celeron and Pentium models

Ensure that your choice of processor fits the power requirements.

Memory Capabilities

When upgrading or replacing RAM, consider these specifications:

Speed: Supports PC3-8500 (DDR3-1066), PC3-10600 (DDR3-1333), and PC3-12800 (DDR3-1600)
Type: Non-ECC, unbuffered RAM
Max Size: Up to 8 GB on 64-bit systems and 4 GB on 32-bit systems

Video Graphics

For detailed graphics specifications, you can check the Cupertino 3 motherboard specifications.

Connecting the Dots

Although HP does not provide user manuals specifically for these motherboards, the links provided will help you find the information and parts you need. By understanding the specifications and compatible components, you can enhance your PC’s performance without any hassle.

If you have any further questions or need help with specific upgrades, feel free to explore forums or reach out to other users for advice. Your HP desktop can serve you well with the right knowledge and components!
