If you’re trying to connect a Lantronix WiBox 2100E serial device server to an Apple ImageWriter II printer, here’s a simple step-by-step guide to help you set up the serial data cable correctly.
First, understand that the connection involves a specific kind of cable that links the device server to the printer. This is important because using the wrong cable can cause communication issues or even damage your equipment.
Look at the back of your Apple ImageWriter II. Most manuals and diagrams show the port location there—usually labeled as the serial or printer port. The diagram linked here shows how the cable should plug into the printer. Keep in mind, if you’re referencing older manuals or diagrams, match the diagram pointing at the back of the computer or printer.
The connection cable needed will typically have a DB9 connector on one end to plug into the device server, and an 8-pin mini DIN connector on the other to connect to the printer. If you can’t find the original cable, there are commercially available alternatives, like the C2G DB9 Female to 8-Pin Mini-DIN Serial RS232 Male Adapter Cable. This is a reliable option if you want a ready-made cable that fits your needs.
It’s helpful to check out detailed manuals for the Apple ImageWriter II for specific port and wiring details. Since the original manuals are hard to find, there are archived versions online that you can access. These documents show the exact port locations and provide coloring or wiring diagrams for the cables.
When setting up, make sure the cable is firmly connected at both ends, and verify that it’s the correct type for both the printer and the device server. Double-checking helps prevent troubleshooting later.
Once everything is connected, turn on your devices and ensure your computer or network recognizes the printer. If it’s not detected, verify that the cable connections are secure, and review your device configuration settings.
This simple process will help you connect your Lantronix WiBox 2100E to the Apple ImageWriter II successfully. If you encounter any issues, consulting the detailed manuals or cable specifications can provide additional guidance.
